MST-712BM55K7RYG 茂仁MOUJEN 3合1警示灯

RMB 0

三合一警示灯 能显示不同状况于红灯黄灯绿灯 亦可以加上蜂鸣器 非常好用

3 in 1 LED signal light三合一警示燈

Rated Voltage 額定電壓

24VDC



Current

電流

Permanent

恆亮

Green LED

---------------

73mA

Yellow LED

-----------------

123mA

Red LED

Without buzzer

125mA

With buzzer

140mA

Blinking

點滅

Green LED

--------------

33 to 73mA

Yellow LED

--------------

55 to 123mA

Red LED

Without buzzer

33 to 135mA

With buzzer

33 to 156mA

Buzzer蜂鳴器

Sound decibel



95 dB at distant

Tone

Permanent

Fast pulse 快續聲

Blinking

Slow pulse 慢續聲

Selector switch 選擇開關

Permanent or blinking恆亮或點滅

Operating temperature 工作溫度

-20 to +50

Life duration 使用壽命

100,000 h

Dimensions

1096 ±10mm

External cable length

700mm

Ingress protection

IP65

Certified Standards

CE
